Convert Revit Projects to XLSX Database with Drawings & Specs via DDC
Automates conversion of Revit (.rvt) files to analysis-ready XLSX data using DDC's RvtExporter.exe, with optional DAE, PDF outputs, and customizable modes via Form UI.
This n8n workflow transforms Revit project files (.rvt) into open, structured data formats like XLSX for databases, plus optional 3D models (DAE) and PDF drawings/specifications. It leverages the RvtExporter.exe from the DDC Revit toolkit, launched via a user-friendly Form UI trigger that accepts inputs for file paths, export modes (basic: 309 categories, standard: 724, complete: all 1209, or custom), and feature flags like bounding box, schedules, sheets-to-PDF, or skipping certain outputs.
Ke
- Platform
- n8n
- Category
- E-commerce
- Price
- $14.99
- Creator
- Arjun Radu
- Revit
- BIM
- CAD
- Data Extraction
- Conversion
- Automation
- DDC
- XLSX
- DAE
How to import this workflow into n8n
- 1Purchase or download the workflow to get the n8n workflow JSON file.
- 2In your n8n instance, open Workflows and choose "Import from File" (or paste the JSON with Ctrl+V on the canvas).
- 3Open each node marked with a credential warning and connect your own accounts and API keys.
- 4Run the workflow once manually to verify the data flow, then toggle it to Active.
