Fix LangGraph InvalidUpdateError: Must write to at least one of ['input', 'plan', 'past_steps', 'response']

How to Fix It

Solution 1: Ensure all state fields have default values (Recommended)

This fix comes from the solution comment by Halil3509 in the GitHub issue. If you have defined your state with Optional fields, you must provide a default value for each field. For example, instead of:

from typing import TypedDict, Optional

class PlanExecute(TypedDict):
    input: str
    plan: list[str]
    past_steps: list[tuple[str, str]]
    response: Optional[str]

Define it with a default value:

from typing import TypedDict, Optional

class PlanExecute(TypedDict):
    input: str
    plan: list[str]
    past_steps: list[tuple[str, str]]
    response: Optional[str] = None

Alternatively, you can use a total=False TypedDict or a dataclass with defaults. The key point is that every field in the state must have a default value, or your node must always write to every field. In the example code from the issue, the execute_step node only writes to past_steps:

async def execute_step(state: PlanExecute):
    objective = state["input"]
    task = state["plan"][0]
    agent_response = await agent_executor.ainvoke({"objective": objective, "input": task, "chat_history": []})
    return {
        "past_steps": [(task, agent_response["result"])],
    }

If response is Optional[str] without a default, this node will fail because it does not write to response. Adding a default value of None to response fixes the issue.

Solution 2: Write to all required state keys in every node

If you cannot or do not want to add default values to your state fields, you must ensure that every node function returns a dictionary that includes all keys defined in the state TypedDict. For the PlanExecute state, that means every node must write to input, plan, past_steps, and response. For example:

async def execute_step(state: PlanExecute):
    objective = state["input"]
    task = state["plan"][0]
    agent_response = await agent_executor.ainvoke({"objective": objective, "input": task, "chat_history": []})
    return {
        "input": state["input"],
        "plan": state["plan"],
        "past_steps": [(task, agent_response["result"])],
        "response": None,  # or some default
    }

This approach is more verbose but works if you prefer not to use defaults. Note that if you have many nodes, this can become repetitive and error-prone.

Solution 3: Check for extra keys in the returned dictionary

If you are sure your state fields have defaults, verify that your node is not returning extra keys. For instance, if your node returns:

return {
    "past_steps": [(task, agent_response["result"])],
    "unexpected_key": "value"
}

LangGraph will raise the InvalidUpdateError because unexpected_key is not in ['input', 'plan', 'past_steps', 'response']. Remove any keys that are not part of the state schema.

If Nothing Works

If the above solutions do not resolve the error, consider the following escalation paths:

1. Check your LangGraph version: Ensure you are using the latest version of LangGraph. The bug may have been fixed in a newer release. Run pip install --upgrade langgraph.
2. Open a GitHub issue: The original issue was filed on the LangGraph GitHub repository. If you have a minimal reproducible example, open a new issue at https://github.com/langchain-ai/langgraph/issues with a descriptive title, the exact error message, and your code.
3. Search the LangGraph documentation: The official documentation at https://langchain-ai.github.io/langgraph/ has a search feature. Look for "InvalidUpdateError" or "state schema" for more examples.
4. Workaround: If you are blocked, consider restructuring your graph to use a single node that writes to all state keys, or use a reducer that merges state updates. For example, you can use a custom reducer function to handle partial updates.

How to Prevent It

To avoid this error in the future:

• Always provide default values for Optional fields in your state TypedDict. This is the simplest and most reliable way to prevent the error. Use Optional[str] = None or Optional[list] = [] (but be careful with mutable defaults; use None and handle it in your code).
• Design your nodes to write only to the keys they need to update, but ensure that all keys have defaults. This keeps your code clean and avoids the error.
• Use a consistent state schema across all nodes. If you add a new field to the state, update all nodes that might run after it to include that field in their return dictionaries.
• Test your graph with a simple linear flow first before adding complex branching or cycles. This helps catch state mismatches early.
• Use type hints and static analysis (e.g., mypy) to catch missing keys in your node return dictionaries before runtime.
